A team in saturation cannot leave the vessel by the usual means because they are pressurised and would need days to decompress. The solution is a hyperbaric evacuation capsule that is launched with the divers inside and under pressure, towed or recovered, and then mated to a shore complex where decompression is completed.
There is a question that always comes up once someone learns how saturation divingworks: if the divers live pressurised for weeks inside a system installed on a ship, what happens if the ship has to be abandoned?
It is a good question, because it points at the method's central contradiction. Saturation exists precisely because decompression is slow; compressing a team once and holding them there is what makes deep work economical. But that same fact turns six people into passengers who cannot use any of a vessel's normal escape routes.
The industry's answer is the hyperbaric evacuation system, and it is probably the most expensive piece of equipment a shipowner ever hopes never to use.
Why no quick fix will do
A diver in saturation has tissues loaded with inert gas in equilibrium with the storage pressure. Bringing them back to atmospheric pressure requires a slow, controlled process, measured in days, which is the final decompression of the campaign.
That process cannot be shortened. There is no emergency mode that compresses it into hours, no drug, no trick. If a saturation system loses pressure suddenly, the outcome for the occupants is catastrophic and immediate. That is why all of the industry's engineering is aimed at making sure pressure is never lost, and at making sure that, if the vessel stops being a safe place, it is the pressurised occupants who leave, taking their pressure with them.
What a hyperbaric evacuation capsule is
It is, in essence, a self-contained, floating pressure chamber, permanently mated to the vessel's saturation system through a transfer trunk. Divers move into it from their living quarters without depressurising, the same way they move into the bell to go to work, through a transfer under pressure.
It has four defining elements. First, the pressure hull, which has to withstand the internal storage pressure as well as the punishment of being launched into the sea. Second, self-contained life support: gas reserves, carbon dioxide absorption, thermal control and enough power to keep the occupants alive with no connection to the vessel. Third, the launch and release system, which has to work even if the vessel has lost power and is listing. And fourth, the means of location and towing, because once it is in the water the capsule is a passive object that someone has to find and recover.
All of that comes with an uncomfortable limitation: several people are confined inside a minimal volume, under pressure, with heat, humidity and noise, and no way out. The occupants of a capsule have done the training, but the real experience would be hard even for people used to living in a tube.
The whole chain, which is what actually matters
The most common misconception is thinking the evacuation system is the capsule. The capsule is only the first link. What saves a team is the whole chain, and every link has to be contracted and tested before the campaign starts.
Launch
Getting the capsule safely off the vessel, with the ship possibly listing and without power. The systems are designed to operate in degraded conditions, and that is one of the parts rehearsed most.
Survival in the water
The capsule floats and keeps life support running, but it drifts. It needs beacons, lights and communication equipment that work on its own power.
Location and recovery
Someone has to reach it, hook it up and either tow it or hoist it aboard another vessel. That requires coordination with the area's search and rescue services and, in practice, a written plan with names, phone numbers and estimated response times for the campaign's specific area.
Reception and decompression ashore
The final destination is a facility able to mate the capsule to a hyperbaric complex and complete decompression under specialist medical supervision. There are not many facilities like that in the world, and that is exactly the critical point in the chain: the campaign is planned knowing which receiving facility would be used and how long it would take to reach it.
What you can take inside
A question that comes up often among people training for saturation is what can be taken into the capsule. The short answer is: almost nothing, and only what the procedure allows.
The interior volume is worked out for the people and the life support equipment, not for personal belongings. Any extra item eats into that space, can interfere with valves and controls, and, if it is flammable, brings an unacceptable risk into a controlled atmosphere. The clothing and kit taken in are specified, just as they are inside the saturation complex itself, where control of combustible materials is just as strict for the same reason.
There is another detail that surprises anyone hearing it for the first time: occupants go in with just what they are wearing, with no documents, phones or belongings. All of that stays on the ship. It is one of the reasons the entry procedure is rehearsed: when the moment comes, there is no time or room to decide anything, only to run a learned sequence.
How it is trained
Training has two sides. For the divers, it is a capsule entry procedure practised until it becomes automatic: what to take, what order to go in, how to secure the hatch, how to manage life support from inside. It is rehearsed periodically during the campaign, the same as an abandon-ship drill on any vessel.
For the surface team — the life support technician, the supervisor and the crew — the exercise is bigger: it covers launch sequences, communication with the outside, and coordination with the vessel's emergency plan. These drills are among the few times the whole operation, including the marine side that normally never touches the diving system, works together.
The scenarios that would force its use
It is worth understanding that hyperbaric evacuation is not the answer to every emergency. It is the answer to one very specific category: one where the vessel stops being a safe place and cannot be made safe again in time.
A fire that cannot be brought under control, a flood that compromises buoyancy, a structural failure, loss of the ability to hold position in conditions that bring the vessel close to a fixed structure. In every one of those cases the saturation system can be intact and working perfectly, and it still has to be abandoned.
Against that there is a whole other category of emergencies that are resolved without evacuating: a diver's medical problem, handled with the hyperbaric doctor remotely and, if needed, a controlled emergency decompression; a failure in a life support component, which has redundancy; or a trapped bell, which has its own recovery procedure. Mixing up the two categories leads to bad decisions both ways, and that distinction is an important part of training in saturation emergency management.
Why it is such a hard engineering problem
Designing a hyperbaric evacuation capsule means squaring requirements that pull in opposite directions.
It has to be a pressure vessel, which calls for thick walls and mass, and at the same time it has to float stably in rough seas, which calls for volume and control of the centre of gravity. It has to be self-sufficient for a long period, which calls for reserves of gas, power and carbon dioxide absorption, and at the same time it has to fit on a vessel where deck space is worth its weight in gold. It has to launch with the ship listing and without power, which demands mechanical systems or accumulators independent of everything else.
And above all, it has to be permanently mated to the saturation system so that occupants can enter without decompressing, which makes it an extension of the hyperbaric complex itself and subjects it to the same inspection and maintenance regime as the rest of the vessel's pressure installation, which is part of the equipment critical equipment on board.
The result is expensive, heavy equipment that takes up deck space for the vessel's whole working life in order, hopefully, never to be used. That it exists anyway, and is drilled regularly, says a lot about how the industry's safety culture has evolved since its early decades.
What this means for anyone working, or wanting to work, in saturation
Three practical things.
The first: when you are shown a vessel, ask about the hyperbaric evacuation system and the shore reception plan for that specific area. It is not an impertinent question; it is exactly what a professional should want to know, and a serious operator will answer without hesitation.
The second: the drill is not a nuisance that interrupts the shift. It is the only time anyone checks whether the chain actually works. Taking it seriously is part of the job.
And the third: the existence of this system explains a good deal of why saturation diving, for all its extremity, has the safety record it has. It is not that the environment is forgiving, it is that the industry has built layers of redundancy over every imaginable failure mode, including losing the ship entirely. Understanding those layers is what separates someone who works with full knowledge of the risks from someone who is simply hoping it will all be fine.
Frequently asked questions
Why can't the divers just get themselves out?
Because their bodies are saturated with inert gas at storage pressure. Decompression takes days and cannot be sped up without causing a serious decompression accident. Coming straight out of a deep saturation is not survivable, so evacuation has to happen while keeping the pressure on.
How long can an evacuation capsule hold out?
It is designed to keep the occupants alive on self-contained life support for a period that allows time for recovery and transfer. The exact figure depends on the system, the number of occupants and the applicable regulations, and it is stated in each unit's certification.
Who receives the capsule ashore?
A receiving facility able to mate it to a hyperbaric complex and complete decompression with medical support. That mating has to be arranged and rehearsed under contract before the campaign starts, not improvised on the day of the incident.
Has this ever actually had to be used?
Hyperbaric evacuation systems are drilled regularly, and having one is a requirement to operate. The details of specific incidents belong to the official investigations for each case, so no figures or events are cited here without a source.
Is this handled by the diver or the surface team?
Both. The divers have a procedure for entering the capsule and securing it from inside, and the life support team and crew manage the launch and recovery. It is a manoeuvre trained separately and together.
Published 5 September 2026 · By Arthur More, professional saturation diver
