The closed bell is a pressurisable steel chamber that carries saturation divers from the vessel's system down to the working depth while keeping its internal pressure constant throughout. One or two divers go out into the water through the bottom hatch while a third, the bellman, stays inside to watch over and assist them.
In saturation the diver doesn't dive down: he's taken down. The closed bell is the piece of kit that makes that way of working possible, and understanding how it works is understanding why saturation is a different regime, and not simply a deeper dive.
Its function is easy to state and hard to deliver: keep the divers at a constant pressure while they move vertically through the water column, and give them a dry refuge with life support just a few metres from the work point.
What it actually is
A closed bell is a steel vessel, usually spherical or cylindrical, with room for two or three people. It hangs from the vessel on a main lift wire and is connected to it by a large-diameter umbilical. It has two hatches: an upper one, which mates with the vessel's saturation system, and a lower one, through which the divers go out into the water.
The key word is cerrada. Unlike a wet bell, the closed bell can be sealed and hold its internal pressure independently of the depth outside. That's what lets the divers rise from the seabed to the deck without decompressing.
How it holds the pressure
The principle is straightforward: the bell is pressurised to the pressure corresponding to the working depth before it separates from the system, and from that point on it acts as a sealed vessel. As it descends, the outside pressure rises until it matches the inside pressure at the planned depth; as it ascends, the outside pressure drops but the inside pressure doesn't change.
That difference in pressure is precisely what makes the lower hatch seal itself. When the bell is below its equilibrium depth, the internal pressure pushes outward and the hatch, which opens inward, is pressed firmly against its seat. No mechanical latch is needed to keep it watertight during the ascent.
The water that doesn't come in
A lot of people assume the bell is full of air and that the water is kept out by some kind of seal. The reality is more elegant. With the lower hatch open at the bottom, the water doesn't rise because the pressure of the gas inside matches the pressure of the water at that depth. The bell works like an upturned glass: there's a free water surface at the hatch, and it stays there.
Lock-out: leaving into the water
Lock-out is the term for the diver leaving the bell to enter the water. The sequence is strictly protocolled.
The divers kit up inside the bell with helmet, hot water suit and harness. Each diver's excursion umbilical is connected to the bell's panels. Gas supply, communications, hot water and the emergency bottle are checked. Only then, with the diving supervisor's authorisation, is the lower hatch opened and the first diver goes out.
The second diver can also go out, or stay inside depending on the operation, but one always has to stay. Excursion time is limited by procedure and controlled from the surface.
Excursion limits
A diver in saturation can't move as far vertically from the bell as he likes. Body pressure is balanced against storage depth, and moving up or down introduces an imbalance. That's why excursion tables exist, setting how many metres above and below the bell's depth the diver can move without risk.
When the job calls for a different depth, the excursion isn't stretched: the system's storage depth is changed instead, which is done in a controlled way and takes time.
The bellman
The bellman is the diver who stays inside the bell while the other works. It isn't a passive role or a rest position: it's the system's rescue element.
His duties are managing the umbilical of the diver who's outside, controlling the length paid out and the slack; keeping constant communication; watching the gas, hot water and general condition of his colleague; and, if something goes wrong, going out into the water and bringing him back.
The bellman is kitted up and ready at all times, and that rescue is explicitly trained for: how to recover an unconscious diver, how to bring him into the bell without help from outside, how to close the hatch and report the emergency. Teams rotate the bellman role between dives.
The bell umbilical
The bell is connected to the vessel by a large-diameter main umbilical that carries everything it needs: breathing gas from several sources, hot water for the suits and to heat the bell itself, electrical power, communications, video and atmosphere-monitoring lines.
Inside the bell are the panels that distribute that supply to each diver's excursion umbilical. It's a system with deliberate redundancy in every critical element. The detail of what each line carries is in the article on the diving umbilical.
Emergency endurance
If supply from the vessel is lost, the bell has to be able to sustain its occupants on its own. It carries emergency gas bottles on board, self-contained CO2 scrubbers, thermal survival blankets and equipment, and batteries for communications and the beacon.
The lost-bell scenario — a bell stuck on the seabed with the divers inside — is one of the most heavily drilled in the industry, and the endurance equipment is sized to give enough margin for a rescue operation.
Mating with the system
At the end of the shift, the bell rises to the deck and mates by its upper hatch with the vessel's saturation system. Pressure is equalised between the two volumes, the transfer hatches are opened and the divers move across into the system, where they eat, sleep and rest at the same pressure.
This mating is called transfer under pressure, and it's what closes the loop of the saturation model: the diver never returns to atmospheric pressure until the final decompression, at the end of the campaign. That's what we explain in the guide on what a saturation diver is.
Closed bell versus wet bell
The wet bell, or wet bell , is a different thing altogether. It's a structure open at the bottom, with no capacity to hold pressure, used in surface-supplied diving as a work platform and as a shelter with a gas pocket where the diver can remove his helmet and talk.
The practical difference is what separates two different ways of working. With a wet bell the diver is still a surface diver: he goes up and down decompressing according to tables, and his bottom time is limited by decompression. With the closed bell the diver lives at pressure and his bottom time is limited by the shift, not by physiology. The full differences are covered in the article on saturation diving versus surface-supplied diving.
Where it's taught
Bell handling isn't part of basic commercial diving training. It's a specific qualification — the closed bell course, or closed bell— taken after building up real experience as a surface diver, and it gives access to saturation work.
The schools that teach this are few and concentrated in the big offshore markets. We list them in the directory of schools, and the full route from scratch is in how to become a commercial diver.
Frequently asked questions
Why doesn't water come into the bell with the hatch open?
Because the gas inside is at the same pressure as the water outside at that depth. The bell works like an upturned glass: the water stays at the level of the hatch and doesn't rise. No seal is needed to stop it.
What is the bellman and why is there always one?
He's the diver who stays inside the bell while the other works. He manages his umbilical, keeps communication going, watches his condition and, if there's an emergency, goes out into the water to rescue him. He's the only immediate rescue resource available at that depth.
How long can the divers be out of the bell?
Excursion time is fixed by procedure and controlled from the surface. There are also vertical distance limits relative to the bell's depth, set out in excursion tables, which can't be exceeded without changing the system's storage depth.
What's the difference between the closed bell and the wet bell?
The closed bell is sealed and holds its internal pressure, which allows saturated divers to be moved without decompressing. The wet bell is open at the bottom, doesn't hold pressure, and is used in surface-supplied diving as a work platform and shelter with a gas pocket.
What happens if supply from the vessel is lost?
The bell has its own endurance: emergency gas bottles, self-contained CO2 scrubbers, thermal survival equipment and batteries for communications and the beacon. That scenario is sized and drilled to give enough margin for a rescue operation.
Published 20 August 2026 · By Arthur More, professional saturation diver
